CASTTEL

Foldable Base:
– Dimensions: 1,60×0,80 m;
– Maximum working height: 8,10 m.



Casttel is a quick-release aluminum scaffolding available with automatic locking hooks certified with european standards EN 1004. Steps and handrails are enhanced. It is composed by a base module (A) measuring
1,96 m, a module (B) measuring 1,50 m a module (C) and one intermediate module (D) of 2,10 m giving a total height of 7,00 m. It is made of tubular aluminum alloy (Ø 42 millimeters) with anti-slip steps. It’s made using few and light components and can be opened very quickly. It is also very easy to be transported and can be assembled in minutes without using any tools. Because is anti-corrosive, it is long lasting.



NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR) NOME DOS SELOS (SUBSTITUIR)



Categories: ,

Description

CASTTEL TOWER

Total Height
m		 Platform Height
m		 Work Height
m		 Modules Stabilizer Platform Base
1.96 0.96 2.96 A No 1 28.00
3.50 2.50 4.50 A+B No 1 41.00
5.00 4.00 6.00 A+B+C Yes 1 72.00
7.10* 6.10 8.10 A+B+C+D Yes 2 104.00

* For external use the 7,10 m Castell Plus S. (A + B + C + D) according to European standard without fit requires 4 counterweights (see optional parts).



MODULE CASTTEL TOWER

Designation REF Total Height
m		 KG
Module A 10339 1.96 28.00
Module B 10340 1.50 13.00
Module C 10341 1.50 30.00
Module D 10342 2.10 32.00
Half Module D 10342.1 - -

OPTIONS CASTTEL TOWER

Options KG
Diagonal e horizontal 1 unidade
Footer platform 13.00
Stabilizers (unit) 4.00
Brake wheels (unit) 1.00
Counterbalance 11.00

TECHNICAL

TECHNICAL

• Folding base height: 1,96 m;
• Folding base working height: 2,96 m;
• Overall dimensions: 1,60×0,80 m;
• Working platform: 1,40×0,60 m (8,77 kg);
• Anti-slip steps (distance): 30 cm;
• 4 wheels with brake: ø 125 mm;
• Capacity: 200 kg/m2 (including 2 people).

MODULES

MODULES

CASTTEL 1,96 m (Module A)
With only 2 components (tower and working platform) (A) the base of Casttel can be opened in a few seconds at a height of 1,96 m (pass through standard doorways 1,60×0,80 m), with a height working 2,96 m.



CASTTEL 3,50 m (Module A + B):
The addition of the final module (B) of 1,50 m for a total of 9 components Casttel can be mounted at a height of 3,50 m with a working height of 4,50 m.



CASTTEL 5,00 m (Module A + B + C)
The intermediate module (C) 1,50 m, includes a set of footers to the working platform and 4 stabilizers for a total of 23 components. The working height is 6,00 m.



CASTTEL 7,10 m (Module A + B + C + D)
With the module (D) Casttel can be extended to a maximum height of 7,10 m, then module C is possible build the module D from 2,10 m to a total height of 7,10 m (height work 8,10 m). Distance between step 30 cm to allow the safe passage of the user for each work platform (in accordance with european standard EN 1004) without the use of interior ladders.

EXTRAS

EXTRAS

Handrail (A)
Guard-rails (A’)
Intermediate Handrails (B)
Work Platforms (C)
Footers (D)
Base Module (E)
Module 7 Steps (F)
End Modules (G)
Module 5 Steps (H)
Diagonals (I)
Horizontal arm (L)
Base (M)
Casters (O)
Stabilizers (P)
Base Handrails (Z)

MODULE A: 1 folding module (6 steps each) with revolving wheels Ø 125 mm, 1 working platform with trapdoor.



MODULE B: 2 end modules (4 steps each), 2 diagonal arms, 2 horizontal handrails, a horizontal handrail base.



MODULE C: 2 intermediate modules (5 steps each), 2 diagonal arms, 2 handrails guard-rails, a set of 4 footers to the work platform, 4 stabilizers.



MODULE D: 2 intermediate modules (7 steps each), 2 diagonal arms, 2 handrails, a working platform with trapdoor.

Video
